The secure and efficient Docker

Flatcar Container Linux is an open-source, community-driven Linux distribution purpose-built for container workloads. It offers enterprise-grade security, automated updates, and a minimal OS footprint, making it ideal for scalable deployments of Docker and/or Kubernetes.

Key Benefits of Flatcar

Benefits of running your Docker stacks using Flatcar

• Minimal footprint – only the bare minimum
  • Ships only the tools required to run containers.
• No package manager is included.
• Immutable file system: nothing can be installed post-deployment.
• Enterprise-grade security – an immutable, read-only file system
  • Read-only root filesystem.
  • Minimal attack surface.
  • Secure by default.
• Automatic, hands-free updates – ensures your systems security and performance.
  • Auto-checks for updates hourly.
  • Updates are written to a separate partition for safe rollback.
  • You can disable auto-updates (not recommended).

Where Flatcar Runs

Cloud providers

Official support:
AWS EC2, Microsoft Azure, Google Compute Engine, Equinix Metal, VMware, DigitalOcean, Hetzner, OpenStack, Brightbox, Linode (Akamai), STACKIT
Community-supported:
Scaleway, OVHcloud

Virtualization platforms:

Official support:
QEMU, libvirt, KubeVirt, Proxmox VE
Community-supported:
VirtualBox, Vagrant, Hyper-V

Running Flatcar on Proxmox VE

Flatcar ships Proxmox-compatible images in qcow2 format. Since Proxmox only accepts ISO in the GUI, we’ll use the CLI to create and configure a VM. You might need/want to add other settings using the qm command, see References, The qm Command

Prerequisites

1. Enable Snippets in Proxmox:
   • Go to: Datacenter → Storage → local → Edit
   • Add Snippets to the content types.
   • Snippets are stored at: /var/lib/vz/snippets/
2. Download a Flatcar Proxmox Image:

wget https://stable.release.flatcar-linux.net/amd64-usr/current/flatcar_production_proxmoxve_image.img

Creating the VM

We will use the CLI to create a VM using the downloaded image.

Step 1: Set VM ID

export VM_ID=20000

Step 2: Create the VM

qm create $VM_ID --cores 2 --memory 4096 --net0 "virtio,bridge=vmbr0" --ipconfig0 "ip=dhcp"

Step 3: Import the disk

qm disk import $VM_ID flatcar_production_proxmoxve_image.img local-zfs

Step 4: Set boot disk

qm set $VM_ID --scsi0 local-zfs:vm-$VM_ID-disk-0 --boot order=scsi0

Step 5: Create Cloud-Init drive

qm set $VM_ID --ide2 local-zfs:cloudinit

Step 6: Create a Cloud-Init Snippet

Step 6.1: Create the file

nano /var/lib/vz/snippets/user-data

Step 6.2: Attach the Snippet to the VM

qm set $VM_ID --cicustom "user=local:snippets/user-data"

Configuring the VM with a Cloud-Init config

The VM can be booted as-is, however you might want to add a OpenStack-style Cloud-Init configuration. What is supported: Setting hostname (hostname is always equal to $VM_ID), Writing SSH keys, Writing network configuration

Configuring Options

The Proxmox GUI does not support setting the custom user-data file. You’ll need to use the command line for this. We need to write the Ignition config as a snippet.
Write a file named user-data containing your Ignition config.

Here is an example

Create the file /var/lib/vz/snippets/user-data and edit it

{
  "ignition": { "version": "3.0.0" },
  "storage": {
    "files": [{
      "path": "/etc/someconfig",
      "mode": 420,
      "contents": { "source": "data:,example%20file%0A" }
    }]
  },
  "passwd": {
    "users": [
      {
        "name": "core",
        "sshAuthorizedKeys": [
          "ssh-ed25519 your-public-ssh-key"
        ]
      }
    ]
  }
}

Finally, tell the VM to use this file as user-data

qm set $VM_ID --cicustom "user=local:snippets/user-data"

Finalize the installation

After the VM starts, you need to

Start the VM

qm start $VM_ID

Set a password for the default user: core

sudo passwd core

Use a strong password!

Set up Portainer

As we need means to set up applications on our Docker VM.
Portainer is the web GUI to manage Docker containers.

1. SSH into the VM
2. Run:

mkdir portainer && cd portainer

docker run -d \
  -p 8000:8000 -p 9443:9443 \
  --name portainer \
  --restart=always \
  -v /var/run/docker.sock:/var/run/docker.sock \
  -v ./portainer_data:/data \
  portainer/portainer-ce:lts

Now, you can manage containers via Portainer’s GUI instead of using the CLI.

References

Flatcar ^[1] Butane ^[2] Ignition ^[3] The qm Command ^[4]
