Local SAMBA using a LXC

Sometimes it's useful to add a hard drive or USB memory stick to a Proxmox host, especially on a mini PC with limited internal expansion. This post is about that.

Set up an Internal SAMBA Server

We will set up a basic SAMBA server for internal use on a privilege CT, for external use a VM is more secure.

Direct device pass-through, the mount point mp0 with a host path, needs a privileged LXC.

Use cases

• Generic NAS-style storage for the home network
• Holding documents that get auto-scanned by Paperless and other apps
• A place for my work related document backups
• Backing a media server e.g., Jellyfin
• Hold our pictures on the network
• Storage for my scripts related to this lab

Prepare the node for a CT to run SAMBA

Add a USB disk to the Proxmox node

Identify the device

Compare the disk list before and after plugging in the USB drive — the new device is your target. Use the Shell and the command lsblk.

Use a stable identifier — Very Important

If you use something like /dev/sdd1 it can change between boots if you have multiple USB disks. Find the persistent identifier and use it for stability.

Find your disk on the node

ls -l /dev/disk/by-id/ | grep -v part

lrwxrwxrwx 1 root root  9 Jun 21 22:05 ata-KINGSTON_SV300S37A240G_50026B7671006C04 -> ../../sda
lrwxrwxrwx 1 root root  9 Jun 21 22:05 usb-Generic-_SD_MMC_MS_PRO_20120926571200000-0:0 -> ../../sdc
lrwxrwxrwx 1 root root  9 Jun 23 14:29 usb-JMicron_PCIe_DD0000000000001D-0:0 -> ../../sdd
lrwxrwxrwx 1 root root  9 Jun 21 22:05 usb-PNY_USB_3.2.1_FD_07211B9A0005BB93-0:0 -> ../../sdb
lrwxrwxrwx 1 root root  9 Jun 21 22:05 wwn-0x50026b7671006c04 -> ../../sda

Use the /dev/disk/by-id/usb-JMicron_PCIe_... path in the LXC config below instead of /dev/sdd1. It survives reboots and re-plugging.

Format the disk

A sensible default for Linux-backed shares is ext4, case-sensitive, supports POSIX ACLs, no file-size limits. If your disk is used you should re-partition it with fdisk/sfdisk fdisk /dev/sdd, before formatting it.

Create the file system

mkfs.ext4 /dev/sdd1

Replace /dev/sdd1 with the actual partition device — or with the persistent /dev/disk/by-id/usb-JMmicron_PCIe_...-part1 path.

Create a CT to host the SAMBA Server

I used a Debian Trixie based CT.

• CPU 1 core
• Disk (system) is small 1-2 GIB
• Disk (USB) is bigger, Used an old laptop M.2 SSD in a USB case, 500 G
• The share can be named whatever, here SAMBA_USB
• RAM 512 for a small Lab but with more users you need more RAM
• In this post the container number is 101, your number is probably different.
• The Server name is samba-1
• We shall add a user, here we use admin

Set up the CT for SAMBA

Create the Mount Point

Inside the LXC, create the directory where the disk will appear (any name works):

mkdir /mnt/SAMBA_USB

Add the Disk to the LXC

Attach the USB disk to the CT

On the node, edit the container's config. Replace 101 with your container ID:

nano /etc/pve/lxc/101.conf

Add this line, but change VENDOR_MODEL_SERIAL to your disks ID

mp0: /dev/disk/by-id/usb-VENDOR_MODEL_SERIAL-part1,mp=/mnt/SAMBA_USB,backup=0

The backup=0 flag excludes this mount point from vzdump backups — usually the right call for large external drives that are the host's target storage rather than its data. If your PBS have the space change to backup=1, even if you back up frequently the no-dup feature keeps the backups small and fast.

Restart the LXC

On the node restart the LXC (e.g., 101) to apply the mount point:

pct reboot 101

If the pct reboot fails with device not found means that the device path for the mount point mp0 doesn't exist on the host.

• Check with ls -l /dev/disk/by-id/ and update the path accordingly.

Install Samba on the new CT

Now we finally move to work on the CT. Install the package inside the LXC and continue with the rest of the installation.

Install the SAMBA Server Package

apt-get update
apt-get install -y samba

Confirm that the service is running:

systemctl status smbd.service

Create a user for the share

Pick a username, here we use admin, change to your own.

Create it as a system user

adduser admin

Set the Samba passwords

Yes they are separate from the Linux system passwords.

smbpasswd -a admin

Set Basic Permissions to the Disk

Set the directory permissions for the user who will own the share e.g., admin.

The setup below is enough for the most basic of setups

Create the directory

mkdir -p /mnt/SAMBA_USB

Set the owner

chown -R admin:admin /mnt/SAMBA_USB

Set the Linux privileges

chmod 770 /mnt/SAMBA_USB

Better Control for Multi-User Setups

When you need to add a second user or more to the share

• Create the user with adduser,
• Register the user with smbpasswd -a,
• Edit the share's valid users =:
  • add the user to the comma-separated list valid users = admin, nalle
  • or use the valid users = @samba_users.setting to include all samba users.

With multiple users sharing the same path with different rights, use ACLs

apt install -y acl

Set ownership

For finer-grained control (multiple users sharing the same path with different rights), use ACLs:

setfacl -R -m "u:admin:rwx" /mnt/SAMBA_USB

For new files we set the default ACL

setfacl -d -R -m "u:admin:rwx" /mnt/SAMBA_USB

Configure the Samba share

The file smb.conf is where you define how a SAMBA Server works. Below is the things we need to add/change for our network storage to work. You might have more needs, depending on the use case.

Make a backup

cp /etc/samba/smb.conf /etc/samba/smb.conf.bak

Edit the SAMBA Configuration

If you know how, you can remove all unnecessary stuff from the file or why not start from a blank file and add the things you require. The smb.conf file is full of comments and plenty of stuff you don't need for a storage server.

nano /etc/samba/smb.conf

Change home directories to Read/Write

# By default, the home directories are exported read-only. Change the
# next parameter to 'no' if you want to be able to write to them.
   read only = no

Add the definition of our new share to the end

[SAMBA_usb]
    comment = Shared USB storage on CT 101
    path = /mnt/SAMBA_USB
    read only = no
    writable = yes
    browseable = yes
    guest ok = no
    valid users = admin
    create mask = 0660
    directory mask = 0770

Test the syntax

You will be informed if there is an issue with the configuration.
You will have a net configuration printed to the screen.

testparm

Restart Samba

systemctl restart smbd

Verify you can access the Share

For LAN clients to use our SMB-share on the CT e.g., 101we need to authenticate with the Samba user e.g., nalle and the password you set with smbpasswd.

The server should appear in the network browser samba-1 or you can connect to the share in your network browser with smb://<IP or FQDN>/<username> e.g., smb://192.0.2.40/nalle.

• macOS and Linux
  • Open your file manager and point it to the samba-1 or smb://192.0.2.40 then Open as and fill in the User and Password
• Windows
  • Open the file manager and point to samba-1 or \\192.0.2.40 and then open using the User and Password

Choose it you want the machine to remember your login credentials or not.

You can use the share both inside the container and across the network:

Troubleshooting

• If the CT starts but /mnt/SAMBA_USB is empty.
  • Probably the disk isn't mounted inside the CT
    Look for SAMBA_USB on the CT: lsblk or on the node: pct df 101
    If it's missing, the mount point is wrongly defined in the configuration, and you need to correct the configuration
• Samba authenticates but writes fails with a Permission denied error message
  • Linux directory permissions don't allow the Samba user to write.
    Check the chown/setfacl commands issued, then correct any errors
• If the share is not appearing in the network browser, but smb://192.0.2.40:/nalle works. This is totally fine. But, you can change this if you like/need.
  • Browseability over the LAN depends on NetBIOS/WS-Discovery.
    To activate it, add nmbd by apt-get install -y samba-common-bin then ensure that nmbd is enabled with systemctl status nmbd if not issue systemctl enable nmbd --now
